Model: 800G OSFP 850nm 100M MPO-16
JH-800G-OSFP-SR8 module is designed for 800GBASE Ethernet and 800Gb/s 2xNDR InfiniBand systems with transmission distance up to 100m over OM4 multimode fiber (MMF), using an 850nm wavelength with an MTP/MPO-16 connector. This transceiver is compliant with IEEE P802.3ck and OSFP MSA standards. Built-in digital diagnostics monitoring (DDM) allows access to real-time operating parameters. With these features, this easy-to-install, hot-swappable transceiver is suitable for various applications, including Ethernet, InfiniBand, data centers, high-performance computing networks, and enterprise core and distribution layers.
| Data Rate | 800G |
| Distance | 100M |
| Wavelength | 850nm |
| Form Factor | OSFP |
| Connector | MPO-16 |
| Case Temperature | 0~70 |
| Voltage Supply | 3.3V |
| Transmitter | VCSEL |
| Receiver | PIN |
| TX Power | -4.6~4 |
| Receiver Sensitivity | -6.4 |
| Power consumption（Max） | 16W |
