型号：1.25G SFP BIDI T1310/R1550nm 20KM LC
JH-1G-WDM-A-20L-35 provides up to 20km of 1000Base-BX throughput over single-mode fiber (SMF) using 1310nm-TX/1550nm-RX wavelengths via LC simplex connectors. This bi-directional unit must be used with another transceiver or network equipment of complementary wavelengths. It provides 1000BASE Ethernet connectivity options for Fast Ethernet, Telecom and Data Centers.
| Data Rate | 1.25G |
| Distance | 20KM |
| Wavelength | BIDI |
| Form Factor | SFP |
| Connector | LC |
| Case Temperature | 0~70/-40~85 |
| Voltage Supply | 3.3V |
| Transmitter | FP |
| Receiver | PIN |
| TX Power | -9~-3 |
| Receiver Sensitivity | -24 |
| Power consumption（Max） | 1W |
