型号：100G QSFP28 1310nm 100KM LC
JH-100G-QSFP28-ZR4+ module is designed for use in 100GBASE Ethernet, providing throughput up to 100 km over single-mode fiber (SMF) using a wavelength of 1310 nm via duplex LC connectors. The 100G signal is carried over four wavelength lanes. It features a BOX+FPC+PCBA separate design for high reliability, airtightness, and efficient heat dissipation. Operating with low power and supporting standard QSFP28 ports, it provides a cost-effective long-reach 100G solution. Compliant with IEEE 802.3ba 100GBASE-LR4, IEEE 802.3bm CAUI-4, and QSFP28 MSA standards, this module supports digital diagnostics via the I2C interface for real-time monitoring. It is suitable for long-distance connectivity in telecom, data center interconnects, service provider networks, wireless fronthaul and midhaul, metro and enterprise networks, and high-performance computing applications.
| Data Rate | 100G |
| Distance | 100KM |
| Wavelength | 1310nm |
| Form Factor | QSFP28 |
| Connector | LC |
| Case Temperature | 0~70 |
| Voltage Supply | 3.3V |
| Transmitter | EML |
| Receiver | SOA+PIN |
| TX Power | 3~6.5 |
| Receiver Sensitivity | -30 |
| Power consumption（Max） | 5.5W |
