JH-25G-SFP28-ZR-80

型号：25G SFP28 1310nm SM 80KM LC

JH-25G-SFP28-ZR-80 module is equipped with LC duplex connectors, reaching a link up to 80km over OS2 single-mode fiber (SMF). This 25G optical transceiver comes with an SFP28 connector, enabling 25 Gbps bandwidth. DOM/DDM (digital diagnostics monitoring) function is supported on the 25G fiber optic transceiver to achieve real-time operating parameters monitoring.

联系我们

产品特性

Hot-pluggable SFP28 form factor
Supports 25.78125Gbps data transmission rate, compliant with IEEE 802.3by 25G Ethernet standard
Maximum power consumption < 2.5W
Commercial operating temperature range: 0~70
Single +3.3V power supply
Supports DDM/DOM digital diagnostic monitoring function, low power consumption design, hot-swappable
Class 1 laser safety certified, compliant with EN 60825-1 standard
Compliant with RoHS 2.0 environmental protection standard, lead-free design
Metro Core, ISP Backhaul

规格参数

Data Rate	25G
Distance	80KM
Wavelength	1310nm
Form Factor	SFP28
Connector	LC
Case Temperature	0~70
Voltage Supply	3.3V
Transmitter	EML
Receiver	SOA+PIN
TX Power	2~7
Receiver Sensitivity	-28
Power consumption（Max）	2.5W

规格书

规格书下载

Datasheet
