JH-400G-OSFP-SR8

型号：400G OSFP 850nm 100M MPO-16

JH-400G-OSFP-SR8 OSFP module, MTP/MPO-16 connector, up to 100m over parallel OM4 multi-mode fiber. It is compliant with OSFP MSA, IEEE 802.3cd protocol and 400GAUI-8 standards.

联系我们

产品特性

Hot-pluggable OSFP form factor
Supports 400Gbps data transmission rate, compliant with IEEE 802.3cu 400G Ethernet standard
Maximum power consumption < 16W
Commercial operating temperature range: 0~70
Single +3.3V power supply
Supports CMIS 4.0 digital diagnostic monitoring, 50G/lane PAM4, low power design, hot-swappable
Class 1 laser safety certified, compliant with EN 60825-1 standard
Compliant with RoHS 2.0 environmental protection standard, lead-free design
Hyperscale DC Spine-Leaf, High-Density Aggregation

规格参数

Data Rate	400G
Distance	100M
Wavelength	850nm
Form Factor	OSFP
Connector	MPO-16
Case Temperature	0~70
Voltage Supply	3.3V
Transmitter	VCSEL
Receiver	PIN
TX Power	-6.5~4
Receiver Sensitivity	-8.4
Power consumption（Max）	16W

规格书

规格书下载

Datasheet
