型号：40G QSFP+ 850/900nm 100M LC
JH-40G-QSFP+-SRBD is a Four-Channel, Pluggable, LC Duplex, Fiber-Optic QSFP+ Transceiver for 40 Gigabit Ethernet Applications. This transceiver is a high-performance module for short-range duplex data communication and interconnect applications. In each direction, it integrates four electrical data lanes into transmission over a single LC duplex fiber optic cable. Each electrical lane operates at 10.3125 Gbps and conforms to the 40GE XLPPI interface.
| Data Rate | 40G |
| Distance | 100M |
| Wavelength | BIDI |
| Form Factor | QSFP+ |
| Connector | LC |
| Case Temperature | 0~70 |
| Voltage Supply | 3.3V |
| Transmitter | VCSEL |
| Receiver | PIN |
| TX Power | -4~5 |
| Receiver Sensitivity | -7 |
| Power consumption（Max） | 3.5W |
